UIS Lighting Adapter: Lighting Adapter with RJ11/12 Connector

UIS Lighting Adapter: Lighting Adapter with RJ11/12 Connector

Regular price: 100.00 zł
Sale price: 100.00 zł

Netto

Tax included. Shipping calculated at checkout.

Variant

Producent: GrowTechnology GmbH
Kod: AC-ADL7
Typ: Controllers
Tagi: kontrolery

Detail

Product description

UIS Lighting Adapter Type-A

Application : Designed for LED lamps with RJ11/RJ12 plugs using PWM or 0-10V dimming protocols.
Compatibility : Lamps from brands such as MARS HYDRO, SPIDER FARMER, VIPARSPECTRA, SUN SYSTEM, VOLT and others that support PWM or 0-10V.
Features : Allows automation of light cycles, schedules, climate triggers and remote control via the AC Infinity app.
Notes : Not compatible with lamps using resistor protocol or with spectrum control.

UIS Lighting Adapter Type-B

Application : Designed for LED lamps with RJ11/RJ12 plugs using the resistor dimming protocol.
Compatibility : Lamps of brands such as CHILLED TECH (GROWCRAFT series), HLG (models with Inventronics and Optotronics drivers), MARS HYDRO (FC, FC-E, SP, TS series with MOSO/MEANWELL drivers), MIGRO (ARAY series), SPIDER FARMER (SE and SF series with MOSO/MEANWELL drivers).
Features : Like Type-A, it allows automation of light cycles, schedules, climate triggers, and remote control via the AC Infinity app.
Notes : Not compatible with lamps using PWM or 0-10V protocols.

Technical comparison

Characteristic	Type-A	Type-B
Dimming protocol	PWM / 0-10V	Resistor
Lamp connector	RJ11 / RJ12	RJ11 / RJ12
Cable length	10 feet (approx. 3 meters)	10 feet (approx. 3 meters)
UIS™ Compatibility	Yes	Yes
Control via app	Yes	Yes
Comments	Incompatible with resistor protocol or spectrum control	Not compatible with PWM and 0-10V protocols

Key Features

Integration with the UIS™ ecosystem : Both adapters allow you to connect third-party lamps to AC Infinity controllers such as Controller 69, 69 PRO, 69 PRO+ and AI+.
Automation and Remote Control : With the AC Infinity app, you can remotely manage your lights, set schedules, monitor climate data, and receive notifications.
Daisy-chaining : Once the first lamp is connected to the controller, it is possible to daisy-chain subsequent lamps from the same manufacturer using their own connection methods.
Firmware Updates : In some cases, a UIS™ driver software update via the AC Infinity app may be required to ensure full compatibility with the adapter.

Tips for choosing an adapter

Type-A : Select if your lamp uses a PWM or 0-10V dimming protocol.
Type-B : Select if your lamp uses the resistor dimming protocol.

If you are unsure which dimming protocol your lamp supports, please check the manufacturer's technical specifications or contact their technical support department.
